Tokyo Hy-Power HL-400B
| Type: |
HF all-mode Linear Amplifier |
| Frequency Range: |
10-80 m |
| Voltage: |
13.8 VDC |
| Current Drain: |
Max 33 A |
| Drive power: |
5-15 W |
| Maximum output power: |
AM/FM/CW: Max 200 W
SSB: Max 350 W (PEP) |
| Dimensions (W*H*D): |
260 x 133 x 293 mm |
| Weight: |
? Kg |
| Manufactured: |
198x-19xx |
| Other: |
Preamp 20-24 dB |
